Self Service Retail Kiosk
Model DT-285A , Self Service Retail Kiosk ,self ordering kiosk , self check in / check out application.
Send Inquiry
Product Introduction
Product Description
A Self Service Retail Kiosk is an interactive, unattended hardware terminal that enables customers to independently complete retail tasks-such as scanning/purchasing goods, placing orders, checking inventory, or redeeming loyalty rewards-without staff assistance, leveraging touchscreens, scanners, payment modules, and cloud connectivity. It has become a core digital tool for modern retail, reducing wait times, cutting labor costs, and boosting transaction efficiency.
Product Design Layout
Product Application
Self-Checkout Kiosks (most common): Customers scan barcodes/RFID, review carts, pay (cash, card, NFC/mobile wallet), and print receipts. Often with weight sensors and camera vision to prevent shrinkage. Used in supermarkets, convenience stores, and big-box retailers.
Self-Ordering Kiosks: For QSRs, cafes, and fast-casual restaurants-customers browse menus, customize orders, pay, and receive a pickup ticket. Reduces order errors and speeds up service during peak hours.
Product Specification
| Components | Detail Description |
| Touch monitor | Embedded Or Desktop Type |
| (Indoor /Outdoor) | 15inch , 17inch , 19inch (4:3) ,18.5inch ( 16:9) ,21.5 , 23.8 , 27 , 32inch , 43 inch |
| Brightness : 250 -1000 nit or other | |
| Receipt printer | Brand Custom / Epson/ Star / Zebra/ Citicen |
| 80 mm width paper , Model Custom K80/2480H /VKP80II/III | |
| A4 printer | HP / Brother / Leamark/ Fuji Xerox/ Kyocera or Other |
| Black and white printer Or Color printer | |
| Paper box : Standard 150 pieces or 250 pieces , addtional box 250 pieces or 500 pieces | |
| With paper out alarm software(SDK ) | |
| Payment terminal | Brand Verifone /Ingenico /Pax /Nayax |
| Embedded type : Motor Card reader Or Manual Card reader Or Swipe card reader | |
| For Example : Card reader Verifone UX300 ; Pin Pad Verifone UX 100 ; NFC Verifone UX 400 | |
| RFID / NFC card reader | Brand : Creator , ACT , ACR |
| Card dispenser | Brand Creator / ACT / TTCE / Omron / Sankyo |
| Read or Writer or dispenser ( Magnetic card Or Chip card Or RFID card or SIM card ) | |
| Solution 1: Single casstte : 150 peices , Addtional 100 peices for optional | |
| Solution 2: Dual cassttes : 200 peices , Addtional 100 peices for optional | |
| Solution 3: Three cassttes : 150 peices , Addtional 150 peices for optional | |
| Solution 4: Four cassttes : 400 peices , Addtional 400 peices for optional | |
| Optional Function : Add barcode scanner to scan 1D or 2D code on the SIM card , like Telecom kiosk | |
| Card printer | Brand Seaory/Fagoo/Evolis |
| Product type : black and white printer or Color printer Or other | |
| Read or Writer or dispenser ( Magnetic card Or Chip card Or RFID card or SIM card ) , school card ,health card | |
| Card box capacity : 100 pieces or 400 pieces | |
| Camera | Brand SHIXIN/ Logitech or other brand |
| 2.0 mega , 3.0 mega , 5.0 mega pixel , depend on resolution , USB interface | |
| Computer | Product type : Embedded type |
| Industrial Motherboard H81 (VGA or HDMI , 1-2 LAN, 6-14 USB , 6-12 RS 232 ) | |
| CPU Intel I 3, I5 , I7 ; RAM 4G ,8G ,16G ; HDD 1T or SSD 128G /256G /512G /1T Optional | |
| OS ( test version ) :window 10 or 11 with or without original lience | |
| Andriod RK 3288 or RK 3299 | |
| Coin acceptor | Brand : CPI G13 / other |
| which currency and what size for each denomination | |
| Coin dispenser | Brand : CPI / ITL or other |
| Coin recyler | Brand : CPI / ITL or other |
| Cash acceptor | Brand : CPI , MEI , Cashcode , JCM , MEI, Moneycontrol |
| Which currency and what size for each denomination | |
| Casstte capacity : 600 , or 1000 or 1500 or 2000 pieces | |
| Cash dispenser | Brand : Fujitsu , Glory ,GRG |
| 500 or 1000 or 2000 or 3000 pieces or each casstte | |
| Cash recycler | Brand : MEI, Glory ,Fujitsu ,GRG |
| Barcode scanner | Brand : Honeywell , Newland , or local China brand |
| support 1D and 2D scanner on the paper or phone , USB interface | |
| ID/Passport scanner | Brand :Wintone, Desko, 3M or other brand |
| Scaning ID/Passport image , MRZ code | |
| Scan RFID Chip at back of passport for optional | |
| Fingerprint | Brand : ZKTECO, Digital personal URU,other brand |
| Optical fingerprint module or Capacitive fingerprint module | |
| Cabinet | 1.2--1.5 mm cold roll steel or stainless steel or Galvanized plate |
| Powder coat paint , Color optional , Choose number from RAL card or Pantone | |
| Built-in Stereo speaker / Lable Screen print LOGO | |
| back panel RJ-45*2, Auido controller, Power input and switch | |
| Other Parts | Alarm device ; Door contact ; Handset ; Microphone ;proximity sensor ;Indicate light |
| Package | Inner foam , wooden case |
Exhibition Show &Customer Visit
Delivery Package Way
FAQ Details
1. About Hardware Parts Configurations
A.Suggest best quality hardware solution with lower cost ;B.Suggest and compare different brand and model hardware parts as optional to help client to save cost ;C.Confirm what configurations need , what function need , like monitor size , touch screen , thermal printer , card reader and so onD.Supply SDK file ( Software Development Kit)for software development;
2. About Kiosk Design
A.Rich experience kiosk design with much more mold , more than hundreds types kiosk design for reference since 2000 year;B.Customized kiosk hardware solution OEM/ODM since 2000 year ;
3. About Kiosk Quality
A.With ISO Quality Management System ;B.Professional hardware engineers and designers ;C.More than 26 years kiosk experiences since 2000;D.Control each process like 3D structure ,CAD drawing , Laser cutting , CNC punching , Bending, Welding , Painting ,Assembling , Testing , Packaging ;E.Testing and Aging more than 48 hours to make sure good quality and product stability before delivery;
4. About Warranty
A.12 months warranty for whole machine .B.Check and guide hardware operation or test remotely ;C.During the warranty, repair and replace the defective parts for free ;D.After warranty , repair and charge part cost. suggest to prepare some backup parts for urgent need when bulk order ;
5. About Delivery
Help client to reduce freight cost ,For example : package way ,delivery way by airplane or by sea and so on ;
6. About Unit Price
A.Suggest best quality brand and model hardware parts with lower cost ;B.Different hardware parts with same function , also different cost ;C.Kiosk unit depend on hardware parts cost & design & customized full project all in one cost ;
