Thermal Ticket Printer Custom KPM180H
Product Description
- Best print quality (200dpi or 300dpi)
- Adjustable paper width: from 20mm to 82.5mm
- Paper thickness: from 70 to 255 gr/m2
- Paper roll or fan fold tickets
- Printing > 200 mm/s
- Tear off or cutter (1Ml cuts) with optional dispenser
- Label processing (tear off and cutter)
- Print head life: 100Km
- 1D and 2D barcode printing: UPC-A, UPC-E, EAN13,EAN8, CODE39, ITF, CODABAR, CODE93, CODE128, CODE32, PDF417, DATAMATRIX, AZTEC, QRCODE
- RS232 / USB (or Virtual COM) / Ethernet interfaces
- Drag&drop for graphics and logos
- True Font character support; Font: any language available
- Sensors: Head temperature, paper presence, mobile detectors of black mark or translucent gap/hole (setting by software), cover open, external low paper
Product Application
Characteristics
The smallest printer on the market!
Powerful processor inside (2MB flash)
Hot swap function
Automatic ticket ejector (optional)
SNAP-IN power supply connector and ON/OFF button
Back connections, feed and print buttons, both at the front and back
Applications
Coupon/voucher printing
Boarding pass and luggage tag printer (AEA)
Parking tickets
Metro and bus tickets
Self service ticketing
Theme parks ticketing
Healthcare wristband printing
Label printing
Product Specification
| Printing Method | Thermal with fixed head |
| Number of dots | 8 dots/mm to 200 dpi
|
| Resolution | 200 dpi or 300 dpi |
| Printing (mm/sec) | 200 mm/sec to 200 dpi
|
| Character set | PC437, PC850, PC860, PC863, PC865, International |
| Supported Barcode | UPC-A, UPC-E, EAN13,EAN8, CODE39, ITF, CODABAR, CODE93, CODE128, CODE32, PDF417, DATAMATRIX, AZTEC, QRCODE |
| Printing Format | Height and width from 1 to 8, bold, reverse, underlined, italic |
| Printing Direction | Straight, 90°, 180°, 270° |
| Paper width | from 20 mm to 82.5 mm |
| Paper weight | from 70 to 255 g/m² |
| Paper thickness | Max 270 µm |
| Printing width | 80 mm |
| Emulation | CUSTOM/POS, SVELTA |
| Interfaces | RS232 / USB (or Virtual COM) / Ethernet |
| Data Buffer | 16 Kbytes |
| Flash Memory | 1 Mbytes internal + 8 Mbytes external (of which 4Mbytes available for user) |
| RAM Memory | 128 Kbytes internal + 8 Mbytes external |
| Graphic Memory | "Drag&Drop" graphics and logo |
| Drivers | Windows® (32/64 bit) – only on request WHQL and silent installation;
|
| Software Tools | PrinterSet; Status Monitor, CustomPowerTool, Custom Windows API |
| Power supply | 24 Vdc±10% |
| Medium consumption | 1.5A (12.5% dots turned on) |
| MTBF | 113,000 hours (electronic board) |
| Head Life | 100Km / 100M pulses |
| MCBF | 1,000,000 cuts |
| Operating temperature | -10°C to +60°C |
| Dimensions | 149,5(L) x 67(H) x 108(W) mm |
| Weight | 1.5 Kg |
Delivery Package Way
Exhibition Show &Customer Visit
FAQ Details
Q: Can I buy sensor accessories separately or only bundled with load cells?
Both. Many customers purchase junction boxes, transmitters, or indicators separately as replacements or for system upgrades. We also offer bundled kits with load cells at discounted prices.
Q: What material for kiosk cabinet ?
A: If indoor kiosk ,then use 1.2-1.5 mm thickness cold roll steel ; If outdoor for anti rust , then use Galvanized sheet or stainless steel
Q: What color for kiosk ?
A: Customized color as client need ; like Pantone or RAL number ;
Q: What backup power supply ?
A: Choose different UPS power model to support based on total power of hardware parts ;
Q: How long for delivery time ?
A: Usually take 30-45 days for kiosk sample design and production ; Less time when bulk order after aprroving sample order ;
